系统（System）
|
|
CPU
|
NVIDIA® Jetson AGX Orin™ 32GB
8-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU
2MB L2 + 4MB L3
NVIDIA® Jetson AGX Orin™ 64GB
12-Core Arm® Cortex®-A78AE v8.2 64-Bit CPU
3MB L2 + 6MB L3
|
|
GPU
|
NVIDIA® Jetson AGX Orin™ 32GB
1792-Core NVIDIA Ampere Architecture GPU with 56 Tensor Cores
NVIDIA® Jetson AGX Orin™ 64GB
2048-Core NVIDIA Ampere Architecture GPU with 64 Tensor Cores
|
|
AI性能（AI Performance）
|
NVIDIA® Jetson AGX Orin™ 32GB
200 TOPS
NVIDIA® Jetson AGX Orin™ 64GB
275 TOPS
|
|
系统内存（System Memory）
|
NVIDIA® Jetson AGX Orin™ 32GB
32GB LPDDR5
NVIDIA® Jetson AGX Orin™ 64GB
64GB LPDDR5
|
|
接口（Interface）
|
|
存储（Storage）
|
64GB eMMC 5.1 ( On NVIDIA® Jetson AGX Orin™ Module)
|
|
显示接口（Display Interface）
|
2×HDMI2.0
1×DP
*同时选择两个视频输出端口
|
|
以太网（Ethernet）
|
2×RJ45 for 10/100/1000Mbps Ethernet
DHCP Client
|
|
扩展槽（Expansion Slot)
|
PCIe
1×PCIe Gen3×4 Slot(*)
1×PCIe Gen3×4 Slot(**)
M.2
1×M.2 2230 E Key PCIe Gen4*1/USB2.0/SDIO Slot
1×M.2 2280 M Key PCIe Gen4×4 Slot
1×M.2 2280 M Key PCIe Gen4×4 Slot(*)
1×M.2 3080 M Key PCIe Gen4×4 Slot(**)
1×M.2 3042 B Key USB3.2 Gen2 ( 10G ) Slot
* Please Select Either 1×PCIe Gen3×4 Slot or 1×M.2 2280 M Key PCIe Gen4×4 Slot to use
Please Select Either 1×PCIe Gen3×4 Slot or 1×M.2 3080 M Key PCIe Gen4×4 Slot to use
|
|
USB
|
2×USB3.2 Gen2 ( Type-A )
2×USB3.2 Gen1 ( Pin Header )
2×USB2.0 ( Type-A )
|
|
微型接口（MIPI）
|
16×MIPI CSI-2 Lanes ( D-PHY 2.1, 4×4 | 3×4+2×2 | 2×4+4×2 | 1×4+5×2 | 6×2 MIPI Lanes, Support MIPI Camera, Capture Card )
|
|
音频接口（Audio）
|
1×3.5mm Line In
1×3.5mm Line Out
|
|
外部通信（Perherial
Communication）
|
1×UART ( Pin Header )
3×GPIO ( Pin Header )
2×CAN Bus ( Pin Header )
2×I2C ( Pin Header )
1×I2S ( Pin Header )
1×SPI ( Pin Header )
3×PWM ( Pin Header )
|
|
视频编码（Video Feature）
|
|
视频编码
|
NVIDIA Jetson AGX Orin™ 32GB
AV1 ( UHP )
．1×4K60 | 3×4K30 | 6×1080p60 | 12×1080p30
H.265 ( UHP )
．1×4K60 | 3×4K30 | 6×1080p60 | 12×1080p30
H.264 ( UHP )
．1×4K60 | 2×4K30 | 5×1080p60 | 11×1080p30
NVIDIA Jetson AGX Orin™ 64GB
AV1 ( UHP )
．2×4K60 | 4×4K30 | 8×1080p60 | 16×1080p30
H.265 ( UHP )
．2×4K60 | 4×4K30 | 8×1080p60 | 16×1080p30
H.264 ( UHP )
．1×4K60 | 3×4K30 | 7×1080p60 | 14×1080p30
|
|
视频解码
|
NVIDIA Jetson AGX Orin™ 32GB
AV1 ( Main Profile )
．1×8K30 | 2×4K60 | 4×4K30 | 7×1080p60 | 15×1080p30
H.265 ( Main, Main10 )
．1×8K30 | 2×4K60 | 4×4K30 | 9×1080p60 | 18×1080p30
H.264 ( Baseline, Main, High )
．1×4K60 | 2×4K30 | 5×1080p60 | 11×1080p30
VP9 ( Profile 0, Profile 2 )
．1×4K60 | 3×4K30 | 7×1080p60 | 15×1080p30
NVIDIA Jetson AGX Orin™ 64GB
AV1 ( Main Profile )
．1×8K30 | 3×4K60 | 6×4K30 | 9×1080p60 | 18×1080p30
H.265 ( Main, Main10 )
．1×8K30 | 3×4K60 | 7×4K30 | 11×1080p60 | 22×1080p30
H.264 ( Baseline, Main, High )
．1×4K60 | 3×4K30 | 6×1080p60 | 13×1080p30
VP9 ( Profile 0, Profile 2 )
．1×8K30 | 3×4K60 | 6×4K30 | 9×1080p60 | 18×1080p30
|
|
SDK
|
|
QCAP
|
采集
High Performance Renderer Image Snapshot
Deinterlace, Alpha Blending Engine Auto Signal Detection
2D/3D Video, Audio and VANC Streams Capture
录制
Encrypt / Sync / Clone / Recording
Time-Shifting / Rewind / Pre-Event / Recording Multi-Streams ( 3D )Recording
Animation Transition Effect
Video Cropping, Scaling and Alpha Blending Engine
流媒体
2D/3D Universal Stream Client 2D/3D Multi-Streams Stream Server
RTSP, RTMP, HLS, SRT, TS, WebRTC. NDI-HX (*), Full NDI (*), Dante AV-H (*)
Animation Transition Effect
Video Cropping, Scaling and Alpha Blending Engine
*需要单独许可证
|
|
QDEEP
|
Al+SDK集成多种算法与深度学习模型于多个领域
应用领域
人脸识别
物体检测
物体分割
光学字符识别
车牌识别
可定制Al视频功能，按需提供
|
|
软件（可选）
|
|
Stream-Catcher-Pro
|
采集
自动“信号侦测”
去隔行、OSD、色彩调整、图像快照、动画与变形功能对PGM的影响
录制
AV1, H.26X MP4, TS
多流录制
计划录制
流
Multi-Streams Stream Server
RTSP, RTMP, HLS, SRT, TS, WebRTC., Full NDI (*), NDI-HX (*),
Dante AV-H (*)
*需要单独许可证
|
|
|
Xtreamer
|
基于网络的用户界面
编码/解码
AV1,H.26X
颜色格式调整
444/422/420,10位/8位选择
录制
MP4,TS
流/网络
RTSP、RTMP、HLS、SRT、TS、WebRTC、NDI-HX(")、全NDI("),
Dante-AV-H-(*)
*需要单独许可证
|
|
|
开发环境（Development Environment）
|
|
OS
|
Ubuntu: 20.04
|
|
内核
|
5.10.104-tegra or Higher
|
|
BSP
|
Linux for Tegra(L4T) R35.3.1 or Higher
|
|
SDK
|
JetPack 5.1.1 or Higher
|
|
环境（Environment）
|
|
电源供应
|
DC input : 19~24V
|
|
功耗
|
TBA
|
|
工作温度
|
标准版本: 0~60 °带气流
|
|
存储温度
|
-20~80℃
|
